The AC Axial Fan 1225 has dimensions of 80mm x 80mm x 25mm and operates on AC power ranging from 100 to 120V. It delivers an airflow of around 22 CFM at a speed of 3200 RPM. This fan features a sturdy die-cast aluminum casing with a black finish, designed to endure harsh conditions and mechanical impacts. The impeller and blades are constructed from thermoplastic materials that meet UL 94V-0 standards for high flame resistance, ensuring both safety and longevity. With dual ball bearings, this fan offers an impressive lifespan of up to 67,000 hours and can be installed in any orientation, providing versatility for various mounting needs. The noise level is kept at a moderate 32 dBA, striking a balance between airflow efficiency and quiet operation.
The manufacturing process for the AC Axial Fan 1225 is defined by precise engineering and strict quality control measures. The production steps include:
Seam Welding and Frame Formation: The fan housing undergoes seam welding followed by flange formation to ensure structural strength and accurate dimensions.
Impeller Production: The blades are created through injection molding using reinforced thermoplastic materials, ensuring consistency and adherence to flammability standards.
Motor Assembly: This fan incorporates impedance-protected motors with windings designed to minimize heat buildup during rotor lock, thereby enhancing motor durability.
Bearing Installation: Dual ball bearings are added to decrease friction and noise, extending the fan's operational lifespan.
Final Assembly and Testing: Each unit is assembled with metal fan guards and mounting hardware, followed by comprehensive performance and safety testing, including checks for vibration, airflow, noise, and electrical safety.
Certification Compliance: The entire production process complies with ISO-9001 and ISO-14001 management standards, as well as UL, CE, TUV, and RoHS2.0 certifications, ensuring product quality and environmental responsibility.
The AC Axial Fan 1225 is extensively used in specialized industrial machinery, such as ice makers and printing machines, where dependable cooling is essential.
Ice Makers: In ice-making machines, the 1225 fan is crucial for dissipating heat produced by compressors and refrigeration components. Its high airflow capacity facilitates efficient heat exchange, helping to maintain optimal operating temperatures, which enhances ice production efficiency and extends the lifespan of the equipment.
Printing Machines: Printing machinery generates considerable heat during operation, particularly in high-speed or large-format printers. The AC Axial Fan 1225 provides focused cooling to electronic control units and mechanical components, preventing overheating and ensuring consistent print quality and machine reliability.
These applications benefit from the fan’s compact design, robust build, and extended service life, making it an excellent choice for demanding industrial settings.
