Frequently Asked Questions (FAQs)
What voltage options are available for the DC Axial Fan 7010?
The DC Axial Fan 7010 is generally offered in 5V, 12V, and 24V DC versions. We can also provide customized voltage options tailored to your specific application needs.
What is the airflow capacity (CFM) of the DC Axial Fan 7010?
The airflow capacity varies between approximately 12 to 25 CFM, depending on the model and voltage. We can modify the fan blade design and speed (RPM) to accommodate your specific airflow requirements.
Is the DC Axial Fan 7010 noisy during operation?
No, the 7010 fan is engineered for low noise output, typically operating between 18 to 28 dBA. It is suitable for environments where noise sensitivity is a concern, such as in medical devices and home electronics.
Can I customize the cable length, connector type, or bearing style?
Yes, as a specialized manufacturer of DC Axial Fans, we offer full customization options, including:
Cable length and type
Connector types (Molex, JST, etc.)
Bearing styles (sleeve, ball, or hydraulic)
PWM or FG (tachometer) functionalities
What is the expected lifespan of the DC Axial Fan 7010?
The typical lifespan for our fans is as follows:
Sleeve bearing: approximately 30,000 hours at 25°C
Ball bearing: around 50,000 hours at 25°C We also offer longer-life versions upon request.
What certifications does the 7010 fan hold?
Our fans comply with international safety standards and carry certifications such as CE, RoHS, UL, CUL, and TUV, meeting export requirements for regions including the EU, North America, and Asia-Pacific.
What are the common applications for the DC Axial Fan 7010?
The 7010 fan is widely utilized in:
Networking and communication devices (routers, switches)
Industrial control panels
Power supplies and inverters
3D printers
Medical equipment
Mini PCs and embedded systems
Is the DC Axial Fan 7010 waterproof or dustproof?
The standard model is not waterproof. However, we can manufacture fans with IP ratings (IPX5/IP55/IP67) upon request for use in harsh environments.
What type of motor is used in this fan?
We utilize high-efficiency brushless DC motors that feature low electromagnetic interference (EMI) and high reliability. Versions with EC motors are also available for enhanced energy efficiency.
Do you accept OEM/ODM orders for the 7010 fan?
Yes, we offer comprehensive OEM/ODM services, which include:
Custom logo printing
Development of private molds
Tailored packaging solutions
Customized performance specifications
What is your minimum order quantity (MOQ)?
For standard models, our MOQ typically ranges from 500 to 1000 units. For custom specifications, the MOQ may vary based on the complexity of the customization.
How do you ensure the quality of your fans?
All fans are produced under ISO 9001 quality management standards. We conduct 100% testing on:
Speed and voltage
Current draw
Noise levels
Vibration
Aging tests
Do you provide samples for testing?
Yes, we offer free or low-cost samples for testing prior to bulk orders. Samples can typically be shipped within 3 to 5 business days.
What is the delivery time for bulk orders?
The lead time is generally:
7 to 15 days for standard models
15 to 25 days for customized models Urgent orders can be prioritized based on our schedule.
What are the differences between the 7010 and the 7025 or 6015 fans?
Compared to the 7025, the 7010 is thinner, making it suitable for designs with limited space, although it has slightly lower airflow. In comparison to the 6015, the 7010 provides a larger fan size and airflow, making it better for cooling higher power components.
Do you offer fans with speed control (PWM)?
Yes, we provide PWM (4-pin) fans that allow for dynamic speed control based on system temperature. Tachometer (FG) output is also available as an option.
What materials are used in the construction of the 7010 fan?
Frame: UL94V-0 rated thermoplastic (PBT or ABS)
Blades: High-strength thermoplastic
Motor: Pure copper winding with a magnetic steel rotor
Shaft: Stainless steel for corrosion resistance
What packaging options do you provide?
Standard bulk packaging
Anti-static bags
Custom printed retail boxes featuring your branding
Can the fan operate continuously 24/7?
Yes, the fan is designed for continuous operation 24/7, making it ideal for mission-critical applications.
How can I become a distributor for your DC Axial Fan 7010?
We welcome global partnerships! Please reach out to our sales team to discuss long-term collaboration, pricing, and exclusive distribution opportunities.
